6
Installation procedure
Outdoor Installation
Installation location
Installation and maintenance space
• Outdoor unit should be placed in well ventilated and dry place.
• Outdoor noise and exhaust should not aect neighbors and around the ventilation.
• Ensure the ground steadily reliable.
• Do not install the outdoor unit on high oil,salt spray or harmful gases.
• Don't being installed to electromagnetic wave can directly radiate an electricity box and keep
o electromagnetic wave radiation possibly, at least more than 3 meters.
• When ice snow overlay area installs outdoor unit, please add to defend snow cover.
• Outdoor unit installed in the shade,avoiding direct sunlight or high temperature heat sources
of radiation.
• Do not install in dusty or polluted place to prevent outdoor unit heat exchanger jam.
• The outdoor unit should install in the public unapproachable place.
As shown below, install the outdoor unit should allow sucient space for handing and
maintenance.
Case 1: stumbling block on the inlet ,also upside opens.
Single installation around the opening
Single installation around the closed
Inlet
Outlet
Min200mm
A
H
h
Min360mm
Inlet
Outlet
Min300mm
Min300mmMin150mm
