- 13 -
3-4-1 Function Description: Display the signal.
&RQQHFWRUGH¿QLWLRQ
Pin # Signal Name Description Remarks
1 NC Not connected ʳ
2 NC Not connected ʳ
3 NC Not connected ʳ
4 GND Ground ʳ
5 RX0- Negative LVDS differential data input ʳ
6 RX0+ Positive LVDS differential data input ʳ
7 GND Ground ʳ
8 RX1- Negative LVDS differential data input ʳ
9 RX1+ Positive LVDS differential data input ʳ
10 GND Ground ʳ
11 RX2- Negative LVDS differential data input ʳ
12 RX2+ Positive LVDS differential data input ʳ
13 GND Ground ʳ
14 RXClk - Negative LVDS differential clock input ʳ
15 RXClk + Positive LVDS differential clock input ʳ
16 GND Ground ʳ
17 RX3- Negative LVDS differential data input ʳ
18 RX3+ Positive LVDS differential data input ʳ
19 GND Ground ʳ
20 NC Not connected ʳ
21 NC Not connected ʳ
22 NC Not connected ʳ
23 GND Ground ʳ
24 GND Ground ʳ
25 GND Ground ʳ
26 VDD power supply +12.0V ʳ
27 VDD power supply +12.0V ʳ
28 VDD power supply +12.0V ʳ
29 VDD power supply +12.0V ʳ
30 VDD power supply +12.0V ʳ
LE26B13200
