3. Location of Controls and Components
3-1 Board Location
3-2 Main Board
No. Description
A Board Main Board
B Board Power Board
A Board
B Board
LE26B13200
LE32B13200
TB300711800M
514C3205M02
TB300711700M
514C2632M04
