1
1. PACKING LIST
Parallel remover ................................. 1
Heat resistant pad.............................. 1
Heat resistant pad
Tip (not included)
Cleaning sponge
Holder clip
FM-2022 Parallel remover
● Applicable Models
In order to function, the FM-2022 must be connected to the FM-202 soldering station.
2. SPECIFICATIONS
● FM-2022 Parallel remover
Power consumption
Temperature range
Tip to ground resistance
Tip to ground potential
Cord assembly
Length, less cord
Weight, less cord
140W (24V)
200 – 400°C (400 – 750°F)
< 2Ω
< 2mV (typical 0.6mV)
1.2m (4 ft.)
110mm (w/o tip)
53g (Parallel remover only)
11g (SOP 25L Tip only)
∗ Specifications and design are subject to change without notice.
