MINI PARALLEL REMOVER
Iron holder with a sleep mode
Instruction Manual
l
Thank you for purchasing the FM-2023 mini parallel remover.
Please read this manual before operating the FM-2023. Keep this
manual readily accessible for reference.
l
CAUTION
• TheFM-2023cannotfunctionbyitself.Itmustbeconnectedtothe
HAKKOFM-202orFM-206station.
• Specicinformationcanbefoundintheinstructionmanualforyour
HAKKOFM-202/FM-206station.
TABLE OF CONTENTS
1.PACKINGLIST.........................................................1
2.SPECIFICATIONS....................................................1
3.WARNINGS,CAUTIONSANDNOTES...................2
4.PARTNAMES...........................................................3
5.SETTINGUPTHEFM-2023....................................3
6.OPERATION.............................................................4
7.MAINTENANCE.......................................................7
8.TROUBLESHOOTINGGUIDE.................................8
9.PARTSLIST...........................................................10
10.WIRINGDIAGRAM................................................11
