Hakko Electronics FM2023-05 - Part Names and Diagram; Setting Up the FM-2023; Connecting the Cord; Iron Holder and Sleep Function

3
4. PART NAMES
Heat resistant pad
PlugFixing flange
Iron holder
Component bed
Cleaning sponge
Tip
Plug
Cord
Handle
Button
Connecting cable
5. SETTING UP THE FM-2023
1.Connectorcord
Passtheconnectorcordthroughthehole
intheheatresistantpad.
2.Ironholder
Whentheironholderisconnectedwiththe
HAKKOFM-203orFM-206stationbyusing
aconnectingcable,thesleepfunctioncan
beused.
RefertotheHAKKOFM-203instruction
manualforhowtosetthesleeptime.
DetailedinformationforHAKKOFM-206on
howtosetthesleeptimecanbefoundin
manualsavailableattheHAKKODocument
Portal.Pleasedownloadandrefertoit.
3.Connections
1. ConnectthecordassemblyoftheFM-
2023tothereceptacleofHAKKOFM-
203orFM-206.
NOTE:
WhenMODELFM-2023isconnectedtoFM-206,
be sure not to connect an incompatible device
becauseeachreceptacleconnectordiffers.
2. PlacetheFM-2023intheironholder.
3. Plugthepowercordintothepower
supply.Besuretogroundtheunit.
Push the plug in as far as 
it will go, and try to remove it 
without pressing the release pin.

If it stays in the receptacle 
it is properly seated.
Receptacle
When the plug ‘clicks’, 
it is fully inserted.
NOTE:
Thisproductisprotectedagainstelectrostatic
discharge and must be grounded for full ef-
ciency.
中継コード
Connectingcable
