Hakko Electronics FM2023-05 - Maintenance Procedures; Tip Maintenance; Checking Procedures

7
7. MAINTENANCE
l
Tip maintenance
PleaserefertotheHAKKOFM-203orFM-206Instructionmanual.
l
Checking Procedure
WARNING:
Unless otherwise directed, carry out these procedures with the power switch OFF and the power
UNPLUGGED.
l
 Verifytheelectricalintegrityof
the heater and sensor
1. Checkforabrokenheaterorsensor
Measuretheresistancewhileatroomtem-
perature(15to25°C;59to77°F).Itshouldbe
8
Ω
±10%.Iftheresistanceexceedstheselimits,
replacethetip.
Measure the resistance across the tip as shown.
l
 Checkthegroundingline 1. Unplugtheconnectioncordfromthestation.
2.Measuretheresistancevaluebetweenpin2
andthetip(bothtips).
3. Iftheresistancevalueishigherthan2Ω(at
roomtemperature),removetheblackoxide
orreplacethetipwithanewone.Iftheresis-
tancevaluestilldoesnotdecrease,checkthe
connectioncordforbreakage.
l
 Checkingtheconnectioncord
forbreakage
1.Insertasetofveriedtipsinbothsidesofthe
handle.
2.Measuretheresistancevaluebetweentwo
pins.
Pin1-Pin3 7~9
Ω
Pin5-Pin3 8~10K
Ω
Pin7-Pin4 7~9
Ω
Pin8-Pin4 8~10K
Ω
Ifthemeasuredvalueexceedsabovevalues,re-
placetheFM-2023.
1
4
7
2
8
5
6
3
