Controls and Displays
A: Front
1
[POWER] button
2
[PRESET 1] button
3
[VOLUME +] button
4
[PRESET 2] button
5
[VOLUME -] button
6
[PRESET 3] button
7
[MODE] button
8 LED
9
Infrared sensor
B: Rear
10
Slide switch for L / mono / R
11
[WPS] BUTTON
12
[RESET] button
13
AUX-In socket
14
Mains power supply
15
Thread for wall bracket
C: Remote Control
1
[POWER] button
2
[MUTE] button
3
Internet Radio - Mode
4
DAB Radio - Mode*
5
FM Radio - Mode*
6
AUX - Mode
7
Backlight Level*
8
Media-Player - Mode
9
[MODE] button
10
[EQUALIZER] button*
11
[ALARM] button*
12
[SLEEP] button*
13
[SNOOZE] button*
14
[MENU] button*
15
[PREVIOUS] button
16
[NEXT] button
17
▲▼◄►*
18
[SELECT] (Enter/OK) button*
19
[REWIND] button
20
[Fast-Forward] button
21
[VOLUME] +/- buttons
22
Presets Up / Down buttons
23
[PLAY / PAUSE] button
24
[BACK] button
25
Presets buttons (1-10)
26
[PRESETS / FAVORITES] Menu*
27
[INFO] button*
Note
Buttons marked with an * asterisk have no function on
this radio model.
