5
1 Introduction
Product Overview
The external print servers enhance capability by letting you place your printers at
convenient locations directly on the Ethernet network, and by increasing network printer
performance and management. Please note that the print server does not support printing
with host-based printers, e.g. CAPT, GDI, PPA.
Network Management and Configuration
The print servers support the Simple Network Management Protocol (SNMP), which remote
printer management and a warning. A standard SNMP agent is permanent on these print
servers. Any standard SNMP-based application can be used to access and manage these
print servers.
The print servers provide an embedded web server that can be accessed via a proper web
browser. We also subsidiary Windows-based PSAdmin utility which help administrator to
setup print server environment.
Wireless Specifications
Standard Complies with IEEE 802.11b/g/n standard
Radio Frequency 2.4Ghz ISM Band
Media Access Control
Method
Carrier Sense Multiple Access / Collision Avoidance
(CSMA/CA) with ACK
Modes Ad-Hoc and Infrastructure (User definable)
Data Transfer Rate 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 150Mbps
Output Power 15 ~ 20dBm
Wireless Security WEP (64/128bit) and WPA/WPA2
Components and Features
• 1 USB 2.0 port
• Fast Ethernet network port: RJ-45 for 10Base-T or 100Base-TX
• 1 LED to indicate Status (Orange)
• 1 LED to indicate USB port (Green)
• 1 LED to indicate WLAN status (Orange)
• One Setup CD for Windows 95/98/Me/NT/2000/XP/2003/Vista/7
• One external AC power adapter
• One Quick Installation Guide
• Built-in WPS button
• Built-in Reset button
