Hammond Sk Series User Manual

141
Appendix
MIDI TEMPLATES OF SK2
Template Basic Pedal KBD Use Ex. Zone
Messages MIDI IN
Sequence Pedal Sequence
Local Control
On On On
NRPN
On On On
Program Change
On On On
Drawbar Registration
On On On
Transmit Channel Tx. Upper
11Off
Tx. Lower
22Off
Tx. Pedal
33Off
Rx. Upper
1 1 (disregarded, off )Off
Rx. Lower
2 2 (disregarded, off )Off
Rx. Pedal
3 3 (disregarded, omni) Off
External Zone
Off Off On
Comments
Use this template to record/
playback the performance of
only this keyboard to the exter-
nal sequencer.
Use this template to play on the
Pedal keyboard connecting to
the MIDI IN jack.
Use this template to play only
on this keyboard and control
the MIDI equipment connect-
ed to the MIDI OUT jack with
the External Zone.
Template Use Ex. w/PK Extra Voice
Messages MIDI IN
Pedal ExVoice
Local Control
On On
NRPN
On On
Program Change
On On
Drawbar Registration
On On
Transmit Channel Tx. Upper
Off 1
Tx. Lower
Off 2
Tx. Pedal
Off 3
Rx. Upper
1 (disregarded, off ) 1 (disregarded, off )
Rx. Lower
2 (disregarded, off ) 2 (disregarded, off )
Rx. Pedal
3 (disregarded, omni) 3 (disregarded, off )
External Zone
On Off
Comments
Use this template to play on
this keyboard and the Pedal-
board connected to the MIDI
IN jack and control the MIDI
equipment connected to the
MIDI OUT jack with the Ex-
ternal Zone.
Use this template to use MIDI
IN jack for play only the Extra
Voices with external MIDI key-
board.

Hammond Sk Series Specifications

General

Display	LCD
Effects	Vibrato, Chorus, Reverb
Connectivity	MIDI In/Out, USB, Line Out, Headphone Out
Extra Voice Sections	Piano
Keyboard	61-note waterfall keyboard
