MIDI
24
Internal Zone Page 2 - Octave
From the previous screen, touch the PAGE RIGHT Touch Button once. Page 2 of the Internal Zone Edit Menu
should now display.
The legend just underneath the word “UPPER” should now blink.
Upper Octave Setting
This Advanced Feature Menu Page allows you to select the Octave range in which the Extra Voices will play. The data
chart below shows the options you may select.
UPPER Octave Options
Description Function
-2 The sound is two octaves below the regular pitch.
-1 The sound is one octave below the regular pitch.
0 The sound is at normal pitch.
+1 The sound is one octave above the regular pitch.
+2 The sound is two octaves above the regular pitch.
Turn the VALUE Rotary Control to the right to raise the Octave.
Turn the VALUE Rotary Control to the left to lower the Octave. It is linked with the [OCTAVE UP], [OCTAVE
DOWN] buttons on the top panel.
To Next Page
