Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: Three to four adults are required to assmeble
this product.
Part Description
Quantity
BB
M6x18 countersunk bolt 8+1
49+1
HARDWARE INCLUDED
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
CC
M6x35 combination bolt 4+1
DD
0 combination bolt8x6M 26+1
NOTE: Hardware not shown to actual size.
EE
16+1
AA
BB
CC
DD
EE
FF
FF
Hex wrench 2
AA M6x15 combination bolt
Ground spike
To Next Page
