HAMPTON BAY GFM00469A - Assembly Instructions; Step 1: Connecting Connector Bars and Magnet Plate

1
l
5
Assembly
Insert the left connector bar (B) into the right connector bar (A) and secure the connector bars (A & B) with
M6x15 combination bolts (AA).
Connecting the connector bar with the magnet iron plate
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE
:
Fully tighten all bolts using the hex wrench (FF).
Attach the magnet iron plate (K) to the assembled connector bars (A & B) using M6x15 combination bolts (AA).
