Handicare Eva400 - Dimensions Eva400;450

123
INSTRUCTIONS FOR USE
D is movement in forward direction
* can be 50 or 100 mm lower
depending on the placement of the
mast in the base socket
** can be 50 or 100 mm higher
depending on the placement of the
mast in the base socket
*** is reference measure 700 mm
with max legspreading
585/23 - 880/34.6
685/26.9-980/38.6
440/17.3
700/27.5***
270/10.6
D
1330/52.4**
1310/51.1
880/34.6
550/21.6
60/2.3
220/8.7
450/17.7
410/16.1
1790/70.5*
All dimensions are in mm/inch
Tolerance +/- 5 mm/ 0.2”
Dimensions Eva400/450
2005/78.9*
500/19.7**
115/4.5
