Lifting speed
34 mm/s without load.
Batteries
Two 12V, 2.9 Ah valve-regulated, sealed, lead accumulator (gel-type batteries)
Number of cycles when fully loaded: 300
Internal charger
External: Linak CH01
(9000368) Mains voltage
100-240VAC (50-60 Hz). Max.
400mA
Internal: Included cable. Max. 400mA
Motor (mast)
DC 24V, 5 A. IP X4.
Operationtime: 10% at maxi-
mum continous running of 2
minutes, maximum 5 switching
cycles per minute. Push:
6000N.
DC 24 V, 10 A. IP X4. Operationtime: 10% at
maximum continous operation of 2 minutes, maxi-
mum 5.5 cycles per minute. Push: 10 000N.
Motor (base)
24V, 5 A, IP X4. Operationtime:
10% at maximum continous
operation of 2 minutes,
maximum 5 cycles per minute.
Push: 3000N.
24 V, 3 A, IP X4. Operationtime: 10% at maximum
continous operation of 2 minutes, maximum 5.5
cycles per minute. Push: 3000N.
Sound level
With load: upwards: 43 dB(A)
downwards: 44 dB(A).
With load: upwards: 74.7 dB(A) downwards: 52.6
dB(A).
Material
Aluminum
Emergency lowering
Manual and electrical
Castors
Front 4”, 100 mm, back 4”, 100mm
Weight
74.9 lbs, 34 kg 77.1 lbs, 35 kg
IP class
IP X4
Expected lifetime
10 years
Operating forces
buttons on hand control
4 N
Turning diameter
1340 mm/ 54 inch
Max. load
400 lbs, 180 kg 450 lbs, 205 kg 600 lbs, 270 kg
Eva450
Eva600
Eva400
Technical Information
