Dimensions Eva600 Low legs
All dimensions are in mm/inch
Tolerance +/- 5 mm/ 0.2”
1330/52.4**
1403/55.5
975/38.3
550/21.6
17/0.6
320/12.6
570/22.4
510/20.1
1790/70.5*
2005/78.9*
500/19.7**
115/4.5
16/0.6
66/2.5
D is movement in forward direction
* can be 50 or 100 mm lower
depending on the placement of the
mast in the base socket
** can be 50 or 100 mm higher
depending on the placement of the
mast in the base socket
*** is reference measure 700 mm
with max legspreading
440/17.3
700/27.5***
0/0
D
650/25.6 - 1050/41.3
750/29.5-1150/45.3
