Technical specifications
26
6 Technical specifications
Description
Model Ibis XP
Max. user weight 160 kg
Total length 1040 mm
Total width 595 mm
Total weight excl. batteries 60 kg
Static stability downward 15°
Static stability upwards 15°
Static stability sideways 15°
Range (ISO 7176) 33 Ah/c5
batteries
25 km
Range (ISO 7176) 40 Ah/c5
batteries
31 km
Dynamic stability on slopes
FWD
6°
Dynamic stability on slopes
RWD
14°
Climbing capacity for
obstacles FWD
70 mm
Climbing capacity for
obstacles RWD
50 mm
Climbing capacity for
obstacles RWD with kerb
climber
100 mm
Maximum speed 6 km/h
Seat tilt 15°
Seat angle 0 - 6°
Effective seat depth 440 – 520 mm
Effective seat width 380 – 555 mm
Seat height front 435 – 540 mm
Backrest angle 89 - 120°
Backrest height 520 – 570mm
Lower leg length 390 – 500 mm
Armrest height 180 – 280 mm
Front armrest to backrest 370 – 450 mm
Minimum turning radius
RWD
790 mm
Minimum turning radius
FWD
600 mm
Ground clearance 60 mm
Batteries
Maximum dimensions
batteries FWD (WxDxH)
278x200x180
Maximum dimensions
batteries RWD (WxDxH)
278x358x180
Maximum battery capacity 30 / 40 Ah
Maximum permissible
charging voltage
24 V
Maximum charging
current
10 A
Connector type A DIN 72311
Wheels
Diameter castor wheel 8"
Diameter drive wheel 12,5”
Tyre pressure castor
wheel
2,5 Bar
Tyre pressure drive
wheel
2,7 Bar
