H&S HDII RAKE - Trouble Shooting Guide

TROUBLE SHOOTING
WARNING
MAKE SURE THAT THE TRACTOR IS SHUT OFF AND THE RAKE CAN NOT MOVE
BEFORE SERVICING THE HDII RAKE. MAINTENANCE AND REPAIR SERVICE
WORK TO BE PERFORMED BY A QUALIFIED SERVICE PERSON ONLY.
Main Frame Will Not Open No Electrical Power to Control Box Check and Make Sure There
is Power to Control Box
Blown Fuse or Circuit Breaker Check and Replace Fuse or Circuit
on Tractor Breaker
Hydraulic Lever Not Engaged or Engage Hydraulic Lever or Move
Engaged in Wrong Direction Hydraulic Lever in Opposite Direction
Hydraulic Hoses Not Connected to Check Hydraulic Hoses For Proper
Tractor Properly Connection
Solenoid Valve Sticking or Not Check Solenoid and Valve
Working Properly
Rake Beams Will Not No Electrical Power to Control Box Check and Make SureThere is
Open or Close Power to Control Box
Transport Locks Still Engaged Remove Clip Pin and Swing Self
Storing Transport Locks Toward
Frame (See Page # 11)
Blown Fuse or Circuit Breaker Check and Replace Fuse or Circuit
on Tractor Breaker
Hydraulic Lever Not Engaged or Engage Hydraulic Lever or Move
Engaged in Wrong Direction Hydraulic Lever in Opposite Direction
Hydraulic Hoses Not Connected to Check Hydraulic Hoses For Proper
Tractor Properly Connection
Solenoid Valve Sticking or Not Check Solenoid and Valve
Working Properly
Rake Wheels Will Not No Electrical Power to Control Box Check and Make Sure There is
Raise or Lower Power to Control Box
Transport Lock Hair Pins Still Remove Transport Lock Hair
Engaged Pins and Place in Storage Position
(See Page #11)
Blown Fuse or Circuit Breaker Check and Replace Fuse or Circuit
on Tractor Breaker
Hydraulic Lever Not Engaged or Engage Hydraulic Lever or Move
Engaged in Wrong Direction Hydraulic Lever in Opposite Direction
Hydraulic Hoses Not Connected to Check Hydraulic Hoses For Proper
Tractor Properly Connection
Solenoid Valve Sticking or Not Check Solenoid and Valve
Working Properly
-17-
TROUBLE
POSSIBLE CAUSE POSSIBLE REMEDY
or Close
