H&S HDII RAKE - Page 27

RAKE BEAMS
-25-
FIGURE 2
1
2
3
4
5
6
7
8
9
*
*
10
11
12
13
14
15
16
17
18
19
20
21
22
23
*
24
25
26
27
28
29
30
HD229
HD110
HD230
HD112
HD113
HD114
YNJM32010
HD116
HD117
HD203
HD204
HD118
HD119
YNHX24005
RG103
YNSL28005
YPCT05010
YWFL28005
HD122
3G18
HD123
HD124
HD125
HD126
HD127
HD201
HD128
YWSI24005
HD202
YWLO20005
YNTL20005
YBHH12035
YBHH12100
RAKE BEAM LEFT A
LIFTING PIPE LEFT
RAKE BEAM RIGHT A
LIFTING PIPE RIGHT
STABILIZER TUBING
TURNBUCKLE
HEX NUT, JAM, 1"-8
TURNBUCKLE END
RAKE WHEEL
COMPLETE LH RAKE WHEEL
COMPLETE RH RAKE WHEEL
WIND GUARD
RAKE TOOTH
HEX NUT, 3/4"-10 PLATED
DUST CAP
HEX NUT, SLOTTED, 7/8"-14
COTTER PIN, 5/32" X 1-1/2"
WASHER, FLAT, 7/8" USS
BEARING
BEARING RACE
RAKE ARM
SEAL
PIVOT SPINDLE
RAKE WHEEL SPINDLE
SPRING
COMPLETE SPRING ASSEMBLY
BUSHING
WASHER, LOCK, STAR, INTERNAL, 3/4"
BEAM PLATE
WASHER, LOCK, 5/8"
HEX NUT, TOP LOCK, 5/8"-11
BOLT, 3/8" X 1-1/4" GR. 5
BOLT, 3/8" X 2-1/4" GR. 5
ITEM PART #
DESCRIPTION
NOTE: * MEANS NOT SHOWN
