RAKE BEAMS
FIGURE 2
-27-
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
YWFL12005
YWLO12005
YNTL12005
HD130
HD131
HD175
HD91
HD132
HD214
HD210
HD154
YPHR08040
YNHX16005
HD179
BFR426
HD157
HD158
YNNY08005
HD176
HD177
HD178
YBHH20085
HD231
YNHX20005
YBHH20010
WASHER, FLAT, 3/8" USS
WASHER, LOCK, 3/8"
HEX NUT, TOP LOCK, 3/8"-16
LIFTING CYLINDER MOUNT RIGHT
LIFTING CYLINDER MOUNT LEFT
LIFTING PIPE COLLAR
STANDOFF MOUNTING PLATE
CYLINDER MOUNT
RAKE WHEEL SHORT CHAIN
RAKE WHEEL CHAIN
ACME ROD
HAIR PIN, 1/4" X 5"
HEX NUT, 1/2"
SPRING STOPPER
RAKE PRESSURE HANDLE
PIVOT WASHER
SPINDLE WASHER
HEX NUT, NYLON LOCKNUT, 1/4"-20
SPRING HOLDER WASHER
POLY SPRING HOLDER
TORSION BAR
BOLT, 5/8" X 5" GR. 5
ADJUSTMENT POST RIGHT
HEX NUT, 5/8"-11 PLATED
BOLT, 5/8" X 1-1/2" GR. 5
ITEM 56-60 USED ON MANUAL MODEL ONLY
56
57
58
59
60
T138
HD213
YPCT06020
T143
T144
RATCHET JACK
HANDLE BAND
COTTER PIN, 3/16" X 2"
JACK PIN
HAIR PIN
ITEM
PART #
DESCRIPTION
