H&S HDII RAKE - Page 31

HYDRAULICS (MODEL)
-29-
FIGURE 3
1
2
3
4
5
6
7
8
9
10
11
12
*
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
HD135
HD136
16SV171
BFR122
DWM233
YBHH32015
HD137
HD138
BFR120
YNTL32005
T143
HD139
HD216
DWM268
T144
HD141
HD142
HD143
HD144
HD145
HD147
HD146
WM175
JB82
YPLY12010
DF18
DWM205
X94
HD187
HYDRAULIC CYLINDER 3" x 8"
HYDRAULIC CYLINDER 3-1/2" x 60"
HYDRAULIC LIFT CYLINDER 2" x10"
3/8" UNION ADAPTER
3/8" UNION ADAPTER
BOLT, 1"-8 X 4" GR. 5
TRANSPORT LOCK LEFT
TRANSPORT LOCK RIGHT
.062 ORIFICE
HEX NUT, TOP LOCK, 1"-8
HYDRAULIC CYLINDER PIN
HYDRAULIC VALVE
SOLENOID TUBE ASSEMBLY
9/16" MALE 0-RING TO 3/8" PIPE UNION ADAPTER
CYLINDER CLIP PIN
HYD. HOSE 3/8 X 288" 1/2MP & 3/8MP
HYD. HOSE 1/4 X 288" 3/8MP & 3/8MP
HYD. HOSE 1/4 X 210" 3/8MP & 3/8MP
HYD. HOSE 1/4 X 36" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 96" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 60" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 20" 3/8MP & 1/2MP
1/2" 90° UNION ADAPTER
BUSHING 1/2" TO 3/8"
LYNCH PIN, 7/16" X 1-3/4"
1/2" CHECK VALVE
1/2" MALE QUICK COUPLER
SPACER 5/16 x 1"
SPACER 3/4 x 1"
NOTE: * MEANS NOT SHOWN
ITEM
PART #
DESCRIPTION
