H&S HDII RAKE - Page 33

FIGURE 4
-31-
ITEM
PART # DESCRIPTION
HYDRAULICS(MANUAL MODEL)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
16SV171
HD187
T143
DWM233
BFR122
BFR120
X94
YPHR02020
HD136
WM175
DWM205
HD141
DWM269
HD142
BFR74
HD145
HD144
HD147
HD146
HD143
XR100
HD212
HYDRAULIC LIFT CYLINDER 2" x10"
SPACER 3/4 X 1"
HYDRAULIC CYLINDER PIN
3/8" UNION ADAPTER
3/8" UNION ADAPTER
.062 ORIFICE
SPACER 5/16 X 1"
HAIR PIN, #23-10
HYDRAULIC CYLINDER 3-1/2" x 60"
1/2" 90° UNION ADAPTER
1/2" MALE QUICK COUPLER
HYD. HOSE 3/8 X 288" 1/2MP & 3/8MP
BOSS UNION ADAPTER
HYD. HOSE 1/4 X 288" 3/8MP & 3/8MP
3/8" FEMALE TEE
HYD. HOSE 1/4 X 96" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 36" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 60" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 20" 3/8MP & 1/2MP
HYD. HOSE 1/4 X 210" 3/8MP & 3/8MP
FLOW DIVIDER VALVE
VALVE MOUNT
