H&S HDII RAKE - Page 35

-33-
WIRING (HYDRAULIC MODEL)
FIGURE 5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
S310
S308
HD148
DWM129
HD180
HD160
HD161
S441
HD149
DWM130
61003
DWM326
DWM140
HD174
HD173
HD163
HD207
HD159
16SV235
DWM175
HD150
RED TAIL LIGHT
RUBBER LIGHT MOUNT
LIGHT BRACKET
YELLOW HAZARD LIGHT
COMPLETE CONTROL BOX W/ HARNESS
CONTROL BOX WHIP
MAIN HARNESS
LIGHT MODULE
TAIL LIGHT LOOM
FLOOD/WORK LIGHT
CONTROL BOX DECAL
CONTROL BOX MOUNT
CONTROL BOX BOTTOM
KNOB
PANEL NUT
POLY SHIELD
MOMENTARY SWITCH
MASTER SWITCH
SWITCH BOOT
STRAIN RELIEF
CONTROL BOX TOP
ITEM PART #
DESCRIPTION
