H&S HDII RAKE - Page 37

FIGURE 6
-35-
WIRING(MANUAL MODEL)
S310
S308
HD148
DWM129
MHD1
S441
HD149
DWM130
RED TAIL LIGHT
RUBBER LIGHT MOUNT
LIGHT BRACKET
YELLOW HAZARD LIGHT
FRONT LIGHT LOOM
LIGHT MODULE
TAIL LIGHT LOOM
FLOOD/WORK LIGHT
ITEM
PART #
DESCRIPTION
1
2
3
4
5
6
7
8
