H&S HDII RAKE - Page 45

FIGURE 12
FRONT RAKE WHEEL EXTENSION
NOTE: * MEANS NOT SHOWN
-43-
ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
*
*
*
*
PART #
HD252
HD251
HD259
HD260
HD253
HD246
HD245
HD248
HD128
T143
16SV351
WM140
T144
HD135
HD247
YBHH12090
YBHH20120
YBHH32010
YWFL12005
YWLO12005
YWLO20005
YNHX12005
YNTL32005
HD203
HD204
HD249
HD250
DESCRIPTION
POLE
TURNBUCKLE LONG STUB LEFT
RAKE BEAM LEFT EXTENSION
RAKE BEAM RIGHT EXTENSION
LIFT PIPE
RAKE ARM RIGHT COMPLETE (INCLUDING SPRING
ASSEMBLY) (SEE FIGURE 2 FOR DETAIL)
RAKE ARM LEFT COMPLETE (INCLUDING SPRING
ASSEMBLY) (SEE FIGURE 2 FOR DETAIL)
CYLINDER ROD
BUSHING
CYLINDER PIN
CLOSE NIPPLE .375 X 2
1/2" BALL BALL VALVE
CYLINDER CLIP PIN
CYLINDER (RE-USE STANDARD 3" X 8" CYLINDER)
REAR CYLINDER ASSEMBLY
BOLT, 3/8" X 2-1/2" GR. 5
BOLT, HEX HEAD, 5/8" X 9" GR. 5
BOLT, 1"-8 X 3-1/2" GR. 5
WASHER, FLAT, 3/8" USS
WASHER, LOCK, 3/8"
WASHER, LOCK, 5/8"
HEX NUT, 3/8"-16
HEX NUT, TOP LOCK, 1"-8
COMPLETE LH RAKE WHEEL
COMPLETE RH RAKE WHEEL
RIGHT EXTENSION COMPLETE
LEFT EXTENSION COMPLETE
