-13-
TRANSPORTING
TOWING ON HIGHWAY
Follow state and local regulations when towing farm equipment on public highways. Never tow the
Windrow Merger on a public highway at a speed greater than 20 m.p.h. (32 kph).
TRANSPORT LOCKS
There are three transport locks on the merger. All locks should be used when transporting the unit, and
must be in the open or storage position when operating the merger. The transport locks (ball valves) (C)
for the heads are located at the cylinders that are used to raise and lower the heads. These cylinders are
located to the “inside” of the heads. The pole transport lock is located near the bend in the pole (D).
C D
LIGHTS & REFLECTORS
Lights and reflective safety decals are on the Windrow Merger for safety. Refer to the Decal Placement
Chapter for location.
