-21-
ADJUSTMENTS
OPTIONAL ACCELERATOR ROLLER
Adjust the cam (A) evenly on both sides of the
accelerator to tighten the chain and square the
accelerator to the frame. Improper adjustment will
cause excessive chain wear.
A
