handtmann INOVA User Manual

Description of Function
15.11.2018
DOUBLE-SEAT VALVE INOVA (Type 580)
BA 058000.06 EN 13 / 36
02
Fig. 1: INOVA double-seat valve Type 580
1 Compressed air supply
2 Balancer with integrated upper valve disk
3 Leakage chamber
4 Balancer with integrated lower valve disk (piston insert)
5 CIP outflow for upper and lower flushing chamber
6 Valve actuator
7 CIP connection for upper flushing chamber
8 Valve seat area
9 CIP connection for lower flushing chamber
10 CIP supply
11 Leakage outlet
1
2
3
4
5
6
7
8
9
10
11
