handtmann INOVA User Manual

Technical Data
15.11.2018
DOUBLE-SEAT VALVE INOVA (Type 580)
BA 058000.06 EN 15 / 36
Transport
5 Technical Data
Product range
Materials Stainless steel 1.4301 or 1.4404
Seals EPDM, FDA conform
Surface area ≤ 0.8 µm
size (DN) 50, 65, 80, 100, 125, 150, 200
size (OD) 2“, 2 ½“, 3“, 4“
Other parts
Materials Stainless steel 1.4301
Seals EPDM / HNBR
Surface area polished, matte
Production
Operating pressure 0 - 10 bar
Temperature 0 -95 °C
Pressure impact safety 40-50 bar tested
Control air 5 -8 bar
Cleaning
CIP operating pressure 2 -5 bar
Flushing chamber pressure < 0.5 bar
Temperature 0 – 95 °C / 140 °C
Noise emissions
Operator position noise < 70 dB(A)
