HANGCHA CBD15-A3MJ - Main Part Introduction

8
2.3 Main part introduction
1
2
3
4
5
6
5
7
8
9
10
11
17
16
15
14
13
12
Item Description Item Description
1 Control handle 10 Load wheel
2 Control lever 11 Fork
3 Lift cylinder 12 Wire fixator
4 Drive wheel cover 13
Battery charging plug（built-in plug）
5 Caster wheel 14 Instrument
6 Drive wheel 15 Hood
7 Fault indicator 16 Emergency stop switch
8 Side door (built-in battery) 17 Key switch
9
Charging light indicator (with built-in charger)
