Part Ⅱ：Structure, Principle and Maintenance
1 Drive Unit
1.1 Data sheet
Speed ratio of reduction gear box 24.6857
Max. wheel torque N•m 250
Max. wheel load kg 1000
Drive motor
Rated voltage V 24
Rated power kW 0.65
Rated current A 38
Rated speed r/min 3100
Working system S2=45min
Insulation grade F
Protection grade IP44
Using the environment temperature
℃ -10～+40
The service life of the brush
h ＞1200
Brake
Rated voltage V 24
Rated power W 20
Rated braking torque N•m 4
Rated Air Gap mm 0.15～0.30
Pre-tension torque of the mounting screw
Nm 2.8
