28
5.4 Replacing battery
Procedure:
– Park the truck securely.Before dismantle or
repair the truck, take down the battery plug
firstly.
– Remove the hood (15). See “Removing the
hood”.
– Remove the screws (34), and then remove the
side door(8).
– Remove the battery positive and negative
electrode.
– From the left and right sides, respectively, pull
the battery (35).
Install the battery in the reverse order. Pay
attention to the battery loading position and wiring
is correct.
15
8
34
35
WARNING
Battery box is very heavy, be careful to avoid damage.
Disposal to the waste battery should accord with local environment regulation.
When replacing the battery, ensure that a battery of the same specification,
dimension and weight is fitted.
