HANGCHA CBD15-A3MJ - Standard Technical Data

12
2.5 Standard technical data
The following technical data are all standard data. Our company reserves the right of alteration
and extension.
Characteristics
Model
CBD15-A3MJ CBD15-A3MJ-I CBD15-A3MJ2
Operator type Pedestrian Pedestrian Pedestrian
Load capacity Q (kg)
1500 1500 1500
Load center c(mm)
600 600 600
Wheelbase y(mm)
1225 1225 1225
Weight Service weight with battery kg
220 220 220
Wheels
﹠
Tyres
Tyre type PU PU PU
Tyre size/Quantity,operator side mm Φ210×70/1 Φ210×70/1 Φ210×70/1
Tyre size/Quantity,load side mm Φ80×64/4 Φ80×64/4 Φ80×64/4
Tyre size/Quantity,Additonal wheels mm Φ70×40/2 Φ70×40/2 Φ70×40/2
Tread, operator side b10(mm)
404 404 404
Tread, load side b11(mm)
400 400 400
Dimensions
Lift height h3(mm)
120 120 120
Fork height, lowered h13(mm)
80 80 80
Overall length L1(mm)
1669 1669 1669
Overall width b1(mm)
568 568 568
Fork size s/e/L(mm)
50×160×1150 50×160×1150 50×160×1150
Outside fork width b5(mm)
560/680 560/680 560/680
Ground clearance, center of wheelbase, min m2(mm)
30 30 30
Min, right angle stacking aisle width1000×1200
across forks
Ast(mm)
1850
1
）
1850
1
）
1850
1
）
Min, ringht angle stacking aisle width 800×1200
across forks
Ast(mm)
1900
2
）
1900
2
）
1900
2
）
Outer turning radius, min Wa(mm) 1400
3
）
1400
3
）
1400
3
）
Performance
Travel speed, laden/unladen km/h
4.5/4.8 4.5/4.9 4.5/4.8
Lift speed, laden/unladen mm/s
50/60 50/60 50/60
Lowering speed, laden/unladen mm/s
40/45 40/45 40/45
Max Gradeability, laden/unladen %
6 / 15 6 / 15 6 / 15
Motor﹠
Battery
Drive motor power kW
0.65 0.65 0.65
Lift motor power kW
0.8 0.8 0.8
Battery voltage, rated capacity V/Ah
2×12/85 24/40 2×12/85
