3. Lifting, transportation and towing
3.1 Lifting
Tie the steel rope on the lifting hole and counterweight lifting hole at both ends of the beam of outer
mast firmly and lift the forklift truck with the lifting device. The wire rope connected with one end of
counterweight should be passed through the gap in the overhead guard, to avoid placing any strain on the
overhead guard.
Warning
Only lifting tools with sufficient loading capacity can be used.
Tilt the mast backwards completely when lifting.
When installing the lifting tools, you must be careful to ensure that the tools will not touch
the components or overhead guard of the forklift truck during the lifting process.
Do not lift the forklift truck from the cab frame (overhead guard).
Do not stand under the truck when lifting it.
