 Do not overload.
 Do not push or pull the cargo.
 Do not use non-explosion-proof forklift trucks in flammable and explosive environments.
 Do not use forklift trucks not specially designed for cold storage warehouses in cold storage
warehouses.
1.3 Display and controls
1. Steering wheel
5. Steering column
adjustment switch
9. Lift control lever
13. Multi-functional display
screen
2. Horn button
6. Ignition key switch
10. Tilt lever
14. Emergency stop switch
3. Direction lever
7. Brake pedal
11. Side shift control lever
15. Rocker switch
4. Hand brake
8. Combination light switch
12. Cup holder
16. Accelerator pedal
