INSTALLATION
6.4. CONNECTING THE PROBE TO THE PUMP CONTROLLER
Ensure the probe is connected and calibrated before installation.
1. Remove protective cap and verify the O-ring is in place. 2. Insert the nut onto the probe.
O-ring
Protective cap
Nut adapter
3. Carefully screw the adapter onto the probe taking care
not to damage the O-ring.
4. Insert the probe with the adapter and screw it carefully
into the saddle.
Screw the
adapter
