DESCRIPTION
4
5
6
7
Position Description
1 Tubing fittings
2 Sensor input
3 Cable gland for level sensor
4 Drainage opening
5 Cable gland for alarm cable
6 Cable gland for power cable
7 Enclosure cap
Cabling safety measures. Qualified personnel should perform wiring only.
• A disconnect switch must be installed to break all current carrying conductors. Turn off
power before working on conductors.
• Always disconnect the pump controller from power when making electrical connections.
• Do not run other cables with the power cable through the cable gland.
• Always run all cables through cable glands to maintain IP65 rating and block unused
holes with cable seal plugs.
