SPECIFICATIONS
Level sensor input
(Digital input)
• External switches can be attached to stop the pump and activate the
alarm (low reagent level) when the switch is open and level alarm is
configured in Setup
• Galvanic isolation
Power supply 100 - 240 Vac, 50/60 Hz
Power consumption 15 VA
Environment 0-50 °C (32-122 °F), max. 95% RH non-condensing
Dimensions 90 x 142 x 80 mm (3.5 x 5.6 x 1.8”)
Weight 908 g (36 oz)
Casing Wall mounted, built-in pump, IP65 rated
4.2. HI10063 pH & TEMPERATURE PROBE
Range 0 to 12 pH
Reference Double junction
Junction Cloth
Temperature sensor Yes
Temperature range -5 to 70 °C (23 to 158 °F)
AmpHel
®
Yes
Matching pin Yes
Body PVDF (white)
Top thread 3/4” NPT
In-line mounting thread 1/2” NPT
Cable length 2 m
Connector Quick connect DIN connector
Maximum pressure @ 25 °C (77 °F) 3 bar (43.5 psi)
