Hanshow ESL Controller HS_C09978 Product Manual
2 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
Figure 1-2 shows an appearance example of USB integration AP.
Figure 1-2 USB integration AP
1.1 System architecture
Hanshow ESL system includes PriSmart/ShopWeb, ESL-Working, ESL controller (AP),
Electronic Shelf Label (ESL) and Handheld Terminal (PDA), as shown in Figure 1-3.
Specifically, ESL controller acts as data transmission link to forward data between ESL-
Working and ESLs.
Figure 1-3 System architecture
