Hanshow ESL Controller HS_C09978 Product Manual
3 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
HS_C09978 builds TCP connection with ESL-Working system via USB virtual Ethernet
port and bi-directional 2.4GHz wireless communication with ESLs.
⚫ Downlink: HS_C09978 receives downlink packets from ESL-Working system and
transmits the data like price, inventory and template to ESLs.
⚫ Uplink: HS_C09978 forwards ESLs’ heartbeat packets or other information to the
ESL-Working system.
1.2 Features
The features include:
⚫ Operating System (OS): Embedded Linux, which is responsible for data interaction
with ESL-Working system, including the registration of ESL controller system,
heartbeat packet transmission and so on. Supports OTA upgrade.
⚫ RF system: Two RF modules. Each has the independent antenna, with concurrent
communication.
⚫ Intelligent dual-system: Supports dual-system, with automatic disaster tolerance.
⚫ Memory: Supports 256MB FLASH + 512MB RAM
⚫ Compatibility: Supports all Hanshow ESLs, including LCD and EPD ESLs.
⚫ Management configuration: Support Web configuration.
⚫ Hardware interface: USB port as virtual Ethernet port, power port or serial interface.
⚫ LED indicator: Real-time display working status.
