Hantek DSO5000 Series User Manual

Basic Operation
Noise Reject
HF Reject
LF Reject
Next Page
Vertical V1
V2
Adjust the vertical window by setting two trigger levels.
Select this option and press F3 to choose V1 or V2.
When =
≠
<
>
Select the trigger condition.
Time 20ns to 10.0sec With this option highlighted by pressing F4, turn the
multi-functional knob to set the time span.
Swap Trigger: As a feature of analog oscilloscopes, it gives stable displays of signals at two
different frequencies. Mainly it uses a specific frequency to switch between two analog channels
CH1 and CH2 so that the channels will generate swap trigger signals through the trigger circuitry.
Options Settings Comments
Swap
Trigger
Mode Auto
Normal
Select the type of trigger.
Channel CH1
CH2
Push an option such as CH1, select the channel trigger type
and set the menu interface.
Below list options in submenus. Swap Trigger allows CH1 and CH2 to select different trigger
modes and to display waveforms on a same screen. That is, both channels can choose the
following four trigger modes.
Type Edge
Slope Rising
Falling
Coupling AC
DC
HF Reject
LF Reject
Push F3 or F4 to select the components of the trigger signal
applied to the trigger circuitry.
Type Video
Polarity Normal
Inverted
Standard NTSC
PAL/SECAM
Sync All Lines
Line Number
Odd Field
Even Field
All Fields
Select by F4, F5.
DSO5000 Series Digital Storage Oscilloscope User Manual 34
