Hantek DSO5000 Series User Manual

Basic Operation
Falling Edge Display the falling edge.
Undo Setup Let the oscilloscope recall the previous setup.
5.6.2Help
Push the HELP button to display the Help menu which provides topics covering all the menu
options and controls of the oscilloscope. For detailed information about the Help system, refer to
Section 2.2.
5.6.3Default Setup
When you push the DEFAULT SETUP button, the oscilloscope will display the CH1 waveform
and remove all the others. When you are at the default setup, press F1 to Undo Preset. Then the
oscilloscope returns to the status before default setup. The table below gives the options, buttons
and controls that change settings at default setup.
Menu or System Option, Button or Knob Default Setting
Acquire (Three mode options) Normal
Averages 16
Run/Stop Run
Cursor Type Off
Source CH1
Horizontal (amplitude) ±3.2div
Vertical (time) ±4div
Display Type Vectors
Persist Off
Format YT
Horizontal Window Mode Single-window
Trigger Knob Level
Position 0.00s
SEC/DIV 200μs
Math Operation —
Source CH1-CH2
Position 0div
FFT Vertical Scale 20dB
FFT Operation
Source CH1
Window Hanning
FFT Zoom X1
Measure Source CH1
DSO5000 Series Digital Storage Oscilloscope User Manual 46
