Hantek DSO5000 Series User Manual

Basic Operation
Positive Width Measure the time between the first rising edge and the next
falling edge at the waveform 50% level.
Negative Width Measure the time between the first falling edge and the next
rising edge at the waveform 50% level.
Off Do not take any measurement.
Use the knob V0 or the functional keys F3, F4 to select the type of measurement.
Taking Measurements: For a single waveform (or a waveform divided among multiple
waveforms), up to 8 automatic measurements can be displayed at a time. The waveform channel
must stay in an ‘ON’ (displayed) state to facilitate the measurement. The automatic measurement
can not be performed on reference or math waveforms, or in XY or Scan mode.
5.5.3ACQUIRE
Push the ACQUIRE button to set the acquisition parameter.
DSO5000 Series Digital Storage Oscilloscope User Manual 39
The readouts in big font size on
the menu are just results of the
corresponding measurements.
