Hantek DSO5000 Series User Manual

Basic Operation
Type None
Trigger (Edge) Type Edge
Source CH1
Slope Rising
Mode Auto
Coupling DC
Level 0.00v
Trigger (Video) Polarity Normal
Sync All lines
Standard NTSC
Trigger (Pulse) When =
Set Pulse Width 1.00ms
Polarity Positive
Mode Auto
Coupling DC
Trigger (Slope) Slope Rising
Mode Auto
Coupling DC
When =
Trigger (Swap) CH1
Type Edge
Slope Rising
Mode Auto
Coupling DC
Level 0.00v
CH2
Type Edge
Slope Rising
Mode Auto
Coupling DC
Level 0.00v
Trigger (OT) Source CH1
Polarity Positive
Mode Auto
Time 20ns
Vertical System,
All Channels
Coupling DC
Bandwidth Limit Unlimited
VOLTS/DIV Coarse
Probe Voltage
Voltage Probe Attenuation 10X
Invert Off
Position 0.00div (0.00V)
DSO5000 Series Digital Storage Oscilloscope User Manual 47
