Hantek DSO5000BM Series User Manual

Basic Operation
and remove all the others. When you are at the default setup, press F1 to Undo Preset. Then the
oscilloscope returns to the status before default setup. The table below gives the options, buttons
and controls that change settings at default setup.
Menu or System Option, Button or Knob Default Setting
Acquire (Three mode options) Normal
Averages 16
Run/Stop Run
Cursor Type Off
Source CH1
Horizontal (amplitude) ±3.2div
Vertical (time) ±4div
Display Type Vectors
Persist Off
Format YT
Horizontal Window Mode Single-window
Trigger Knob Level
Position 0.00s
SEC/DIV 200μs
Math Operation —
Source CH1-CH2
Position 0div
FFT Vertical Scale 20dB
FFT Operation
Source CH1
Window Hanning
FFT Zoom X1
Measure Source CH1
Type None
Trigger (Edge) Type Edge
Source CH1
Slope Rising
Mode Auto
Coupling DC
Level 0.00v
Trigger (Video) Polarity Normal
Sync All lines
Standard NTSC
Trigger (Pulse) When =
Set Pulse Width 1.00ms
Polarity Positive
Mode Auto
Coupling DC
