Specifications
Display Type 7 inch 64K color TFT (diagonal liquid crystal)
Display Resolution 800 horizontal by 480 vertical pixels
Display Contrast Adjustable (16 gears) with the progress bar
Probe Compensator Output
Output Voltage,
typical
About 5Vpp into ≥1MΩ load
Frequency, typical 1kHz
Power Supply
Supply Voltage 100-120VAC
RMS
(±10%), 45Hz to 440Hz, CATⅡ
120-240VAC
RMS
(±10%), 45Hz to 66Hz, CATⅡ
Power Consumption <30W
Fuse 2A, T rating, 250V
Environmental
Temperature Operating: 32 to 122 (0 to 50 )℉ ℉ ℃ ℃
Nonoperating: -40 to 159.8 (-40 to +71 )℉ ℉ ℃ ℃
Cooling Method Convection
Humidity +104
℉
or below (+40
℃
or below): ≤90% relative humidity
106 to 122 (+41 to 50 ): ≤60% relative humidity℉ ℉ ℃ ℃
Altitude Operating and Nonoperating 3,000m (10,000 feet)
Random Vibration 0.31g
RMS
from 50Hz to 500Hz, 10
minutes on each axis
Nonoperating 2.46g
RMS
from 5Hz to 500Hz, 10
minutes on each axis
Mechanical Shock Operating 50g, 11ms, half sine
Mechanical
Size Length 313mm
Height 142mm
Depth 108mm
Weight exclusive of packing and
accessories
2.08Kg
Packing Length 385mm
Width 200mm
Height 245mm
Gross Weight inclusive of all accessories
约
2.5Kg
8.2 Accessories
All the following accessories are available by contacting your local HANTEK distributor.
Standard Accessories
Sketch Description
DSO5000 Series Digital Storage Oscilloscope User Manual 73
