Basic Operation
 If no signals are found and no channels are displayed, the oscilloscope will display and
use Channel 1 as the trigger source.
Sine Wave:
When you use the Autoset function and the oscilloscope determines that the signal is similar to a
sine wave, the oscilloscope displays the following options.
Sine Wave Options Details
Multi-cycle Sine Display multiple cycles that have appropriate vertical and
horizontal scales.
Single-cycle Sine Set the horizontal scale to display about one cycle of the
waveform.
FFT Convert the input time-domain signal to its frequency components
and display the result as a graph of frequency versus amplitude
(spectrum). Since it is a math calculation, see Section 5.3.1 Math
FFT for more information.
Undo Setup Let the oscilloscope recall the previous setup.
Square Wave or Pulse:
When you use the Autoset function and the oscilloscope determines that the signal is similar to a
square wave or pulse, the oscilloscope displays the following options.
Square Wave Options Details
Multi-cycle Square Display multiple cycles that have appropriate vertical and
horizontal scales.
Single-cycle Square Set the horizontal scale to display about one cycle of the
waveform. The oscilloscope displays Min, Mean and Positive
Width automatic measurements.
Rising Edge Display the rising edge.
Falling Edge Display the falling edge.
Undo Setup Let the oscilloscope recall the previous setup.
5.6.2Help
Push the HELP button to display the Help menu which provides topics covering all the menu
options and controls of the oscilloscope. For detailed information about the Help system, refer to
Section 2.2.
5.6.3Default Setup
When you push the DEFAULT SETUP button, the oscilloscope will display the CH1 waveform
DSO5000 Series Digital Storage Oscilloscope User Manual 45
