Specifications
Edge Trigger mode: The oscilloscope counts all edges of sufficient
magnitude and correct polarity.
Video Trigger mode: The Frequency Counter does not work.
Acquisition
Acquisition Modes Normal, Peak Detect, and Average
Acquisition Rate,
typical
Up to 2000 waveforms per second per channel (Normal acquisition mode,
no measurement)
Single Sequence Acquisition Mode Acquisition Stop Time
Normal, Peak Detect Upon single acquisition on all
channels
simultaneously
Average After N acquisitions on all channels
simultaneously, N can be set to 4, 8,
16, 32, 64 or 128
Inputs
Inputs
Input Coupling DC, AC or GND
Input Impedance,
DC coupled
1MΩ±2% in parallel with 20pF±3pF
Probe Attenuation 1X, 10X
Supported Probe
Attenuation Factors
1X, 10X, 100X, 1000X
Maximum Input
Voltage
Overvoltage Category Maximum Voltage
CAT I and CAT II 300V
RMS
(10×), Installation Category
CAT III 150V
RMS
(1×)
Installation Category II: derate at 20dB/decade above 100kHz to 13V peak
AC at 3MHz* and above. For non-sinusoidal waveforms, peak value must
be less than 450V. Excursion above 300V should be of less than 100ms
duration. RMS signal level including all DC components removed through
AC coupling must be limited to 300V. If these values are exceeded,
damage to the oscilloscope may occur.
Measurements
Cursors Voltage difference between cursors:
△
V
Time difference between cursors:
△
T
Reciprocal of
△
T in Hertz (1/ΔT)
Automatic
Measurements
Frequency, Period, Mean, Peak-to-peak, Cycle RMS, Minimum, Maximum,
Rise Time, Fall Time, Positive Width, Negative Width
General Specifications
Display
DSO5000 Series Digital Storage Oscilloscope User Manual 72
