Hantek Hantek2D72 - Voltage, Current, and Resistance Measurements; DMM Advanced Measurements; Capacitance, Diode, Continuity, and Hold

a) Press the power button to turn on, then press the "DMM" button to enter to the
multimeter function interface;
b) To measure the DC current greater than 200mA, press the up, down, left and right
keys or F1, F2, F3, F4 multi function keys to select "DC A" or "AC A", and insert the
black pen to the input end of the COM banana socket, and insert the red pen into
the input port of the “A” banana socket;
c) To measure the DC current less than 200mA, press the up, down, left and right
keys or F1, F2, F3, F4 multi function keys to select "DC mA" or "AC mA", and insert
the black pen to the input end of the COM banana socket, and insert the red pen
into the input port of the “mA” banana socket.;
d) Connect the red and black forms to the measured point. The current value of the
measured point will be displayed on the screen.
3. Resistance measurement
a) Press the power button to turn on, then press the "DMM" button to enter to the
multimeter function interface;
b) Press the up, down, left and right direction keys or F1, F2, F3, F4 multi-function
keys to select "Ω";
c) Insert the black pen into the input port of the COM banana socket, and insert the
red pen into the input port of the V/Ω/C banana port;
d) Connect the red and black forms to the measured point. The resistance value of
the measured point will be displayed on the screen.
4. Capacitance measurement
e) Press the power button to turn on, then press the "DMM" button to enter to the
multimeter function interface;
f) Press the up, down, left and right direction keys or F1, F2, F3, F4 multi-function
keys to select " ";
g) Insert the black pen into the input port of the COM banana socket, and insert the
red pen into the input port of the V/Ω/C banana port;
h) Connect the red and black forms to the measured point. The capacitance value of
the measured point will be displayed on the screen.
5. Diode measurement
i) Press the power button to turn on, then press the "DMM" button to enter to the
multimeter function interface;
j) Press the up, down, left and right direction keys or F1, F2, F3, F4 multi-function
keys to select " ";
k) Insert the black pen into the input port of the COM banana socket, and insert the
red pen into the input port of the V/Ω/C banana port;
l) Connect the red and black forms to the measured point. The diode value of the
measured point will be displayed on the screen.
6. On-Off measurement
