S e l e c t i o n
N O . 1
1 3 7 0
- 2 0 0
1
1 0 0 . 0
0 . 0
O F F
E U S ( 0 . 0 % )
U P
Signal Name Description Condition Initial value
Input group
Input signal selection
High limit
Low limit
Decimal point(on voltage input)
Maximum on scale
(on voltage input)
Minimum on scale
(on voltage input)
PV filter
PV bias
Burn-out
Input type and mode selection
Refer to input signal and rang
Refer to input signal and range
( Notice : FR-H > FR-L )
Thermocouple or R.T.D : decimal point
of instrument / DC Voltage : 0~3
-1999~9999
Notice : SL-H › SL-L
Deimal point : according to DP-P
OFF/1~120sec
EUS (-100.0~100.0%)
OFF / UP / DOWN
Always
Always
Always
On voltage
input (mV,V)
On voltage
input (mV,V)
Always
Always
Always
Always
② Maximum and Minimum range
Press key to set Maximum and Minimum range using or
or key. Press key once more to finish.
22
Time setting
Set Year
Set Month
Set Day
Set Mour
Set Minute
Set Second
Set Y, M, D, T.
2000 ~ 2099
1 ~ 12
A l w a y s
Always
A l w a y s
A l w a y s
A l w a y s
A l w a y s
A l w a y s
Present
v a l u e
Present
v a l u e
Present
v a l u e
Present
v a l u e
Present
v a l u e
Present
v a l u e
0 ~ 59
1 ~ 31
0 ~ 23
0 ~ 59
21
7)
Input group setting
8)
Time group setting
When setting, “Input type selection number” must be selected in the input type selection
mode and also “Output type selection number”must be selected in the output type selection
mode before moving to other mode.
If not, data of other group will be changed to prior value.
CAUTION
① Input type selection
After power ON and when PV is indicating, press key for 3 sec to be displayed at
PV and 3 at SV. (If it is not indicated 3, set again in the level setting mode)
Control group is indicated when press key once more. At the time, input group is indicated
when press key and then “Input type and range selection is shown at SV when press .
At this time the input and range is selected by or key. Press key to confirm
③ Decimal point
Parameter is not indicated in T.C and R.T.D input, but when selecting voltage input “Decimal
point”mode is indicated. (set 1 : 0.0, set 2 : 0.00, set 3 : 0.000)
④
Maximum and Minimum on scale
It is the same function as Maximum and Minimum Range setting when R.T.D or thermocouple
input. This mode is indicated when voltage input ( 30, 31, 32, 33 )
⑤ PV filter
When PV value becomes unstable due to effects of noise, the filter helps suppress the unstable
status. (Range: OFF or 1~120sec. initial value: OFF)
⑥ PV bias
Use this function to adjust PV value in cases where it is necessary for PV value to agree with
another recorder or indicator, or when the sensor cannot be mounted in correct location.
(Range : -100.0~100.0% of SPAN, lnitial value : 0.0%)
Setting a value using or or key and press key to finish.
Signal Name Description Condition I nitial value
To Next Page
